Specifacation

• Ports:

• 1x 1394a (6-pin)

• 2x 1394b (9-pin, Bi-lingual)

• Supports Data Transfer Rates of:

• 800Mbps

• 400Mbps

• 200Mbps

• 100Mbps

• TI Chipset

• No Driver required (plug-and-play)

• Simultaneous Operation of Multiple High-performance Devices

• Supports Hot-swapping and Plug-n-Play Connection of Peripheral Devices

• Works with Various Types of FireWire 800 (1394b) and 1394a Devices Including Portable Hard Disk, DV Camcorder, Digital Camera, CD-RW/DVD-ROM Drive and Other Audio/Video Devices

• 1-Lane (x1) PCI-Express with Transfer Rate 2.5Gb/s Full Duplex Channel

• Support Provisions of IEEE P1394b Revision 1.33+

• Compliant with PCI-Express Revision 1.0a

• Compliant with IEEE 1394 OpenHCI Specifications V1.0 and V1.1

• Compliant with IEEE 1394-1995 for a High Performance Serial Bus

• Compliant with IEEE 1394a-2000 Standard

• Fully Backward Compatible to 1394a Specification

• Fully Interoperable with FireWire, iLink, and SB1394 Implementation of IEEE 1394 Standard
