Dedicated PCIe 3.1 x4 bus bandwidth,Integrated TRIM & S.M.A.R.T. Monitoring with TBW Tracking,PCI Express 3.1 x16 Lane Host adapte,Support PCIe 3.1,3.0, PCIe 2.0 motherboard,2x PCIe 3.1 x4 to M.2 Ports.
ModelIO-PCE2824-TM2
Input InterfacePCIe
Output InterfaceM.2
Motherboard SlotPCIe
Transmission Rate
Auxiliary AccessoriesScrew Drive ,mounting screws
Product Size203.7x110.8mm
Features
•2x PCIe 3.1 x4 to M.2 Ports
•Dedicated PCIe 3.1 x4 bus bandwidth
•Integrated TRIM & S.M.A.R.T. Monitoring with TBW Tracking
•PCI Express 3.1 x16 Lane Host adapte
•Support PCIe 3.1,3.0, PCIe 2.0 motherboard
•Compliant with PCI Express M.2 specification 1.0
•Supports data transfer up to 2.5Gb/s,5Gb/s,8Gb/s
•Connects PCIE motherboard to NGFF M Key SSD
•Supports 2230, 2242, 2260, 2280 size NGFF SSD
•8 screw holes available to fix PCB board
•Easy installation & no driver required
•Independent, Stand Alone NVMe SSD Solution
•Smart PCIe Switching Built-In
•Robust, Compact & Efficient – Shield & Cool Your SSD’s
System Requirements
•Supports Windows 7,8,8.1 and 10
•Windows server 2K8,2K12,2K16
•Linux Kernel 3.3 or later
•Mac
Package Contents
•1 x PCIe x 16 to 2 x M.2(M-Key) card
•1 x User Manual
•2 x Screw Drive
•4 x NGFF M.2 SSD mounting screws
