M.2(NGFF) & mSATA SSD to SATAIII card;M.2 specification revision 0.9;Serial ATA Spec. Revision 3.2;Supports M.2 card size: 22*30, 22*42, 22*60;Supports mSATA SSD size:26.8*30,50.95*30;
ModelIO-M2MSTOSA
Input InterfaceM.2(NGFF) & mSATA
Output InterfaceSATA
Motherboard SlotM.2(NGFF) & mSATA
Transmission Rate6Gbps
Auxiliary AccessoriesLow Profile Bracket,Standard Profile Bracket,Screws
Product Size96.9x64.2mm
Features:
M.2(NGFF) & mSATA SSD to SATAIII card;
M.2 specification revision 0.9;
Serial ATA Spec. Revision 3.2;
Supports M.2 card size: 22*30, 22*42, 22*60;
Supports mSATA SSD size:26.8*30,50.95*30;
Supports M.2 B Key Card Type ;
Supports high-speed SATA3/6 Gbps interface.
52-pin mini PCI-e interface;
Compatible with SATA revision 2.6;
Support ATA/ATAP-7 specification;
Power supply system using:3.3V and 1.8V.
Port: standard SATA 22 pin connector
An M.2 SSD will always be the first priority. When both an M.2 and mSATA device are connected the mSATA will not function.
Note: The efficiency mainly depends on M.2(NGFF) & mSATA SSD master IC and the size of the capacity
Package details
1×M.2 (NGFF) & mSATA SSD TO SATA III Card
1×User Manual
1×Low Profile Bracket
1×Standard Profile Bracket
1×Screws
System Requirements
MS Windows, Mac OS, Linux operating system
