Features
Compliant with Bluetooth 2.1 + EDR and V3.0 + HS specifications by on chip software stack
Support for WLAN + Bluetooth coexistence for optimized performance
IEEE 802.11b/g/n compliance
150 Mbps Tx (Transmit) PHY data rate, and 150 Mbps Rx (Receive) PHY data rate
Compliant with PCIe V1.2 or later
Support for legacy and high throughput Wi-Fi modes
1T1R 802.11n Wi-Fi with antenna diversity
Compressed Block ACK(BA)
Compliant with IEEE 802.11i 64-/128-bit WEP encryption, WAP, WPA-PSK and TKIP, and WPA2(with AES-CCM support)
Support Hardware WAPI/16 BSSID
Compliant with IEEE 802.1e WMM and WMM Power Save
Compliant with international regulations for IEEE 802.11d
Support for both long and short guard intervals
Cisco CCX V1.0,V2.0,V3.0,V4.0 and CCX5.0 compliant
Support for IEEE 802.11s mesh networks
Support for BT Class 1 Operation for better Bluetooth range
Support Full-speed Bluetooth operation with Piconet and Scatternet
Shared Bluetooth and Wi-Fi signal receiving path to eliminate the need for an external
System Requirements
Windows 2000/XP/Server2003/2008/2012/Vista/7/8/10
Package Contents
MiniPCI-E to PCI-E Wireless Adapter x 1
User Manual x 1
Driver CD x 1
Note: Contents may vary depending on country/market
