Supports PCIe x16 slot,Support PCIe 3.1,3.0, PCIe 2.0 motherboard,Compliant with PCI Express M.2 specification 1.0,1.1,Supports data transfer up to 2.5Gb(250MB/s),5Gb(500MB/s),8Gb(1GB/s)
ModelIO-PEX85624
Input InterfacePCIe
Output InterfaceU2(SFF-8643)
Motherboard SlotPCIe
Transmission Rate
Auxiliary AccessoriesSAS SFF-8643 cable
Product Size
Features
• Supports PCIe x16 slot
• Support PCIe 3.1,3.0, PCIe 2.0 motherboard
• Compliant with PCI Express M.2 specification 1.0,1.1
• Supports data transfer up to 2.5Gb(250MB/s),5Gb(500MB/s),8Gb(1GB/s)
• Connects PCIE motherboard to NGFF M Key SSD
• Easy installation & no driver required
• Buit-in SFF-8643 plug connector
• SFF -8643 Min SAS HD Version 3.5
• PCI Express Card Electro-Mechanical* (CEM) Specification Rev 2.0
• NVM Express 1.0
System Requirements:
• Windows 7/8/8.1/10 64 bit
• UEFI 2.3.1 or later
• PC with one free PCI Express x16 / x32 slot
Package Contents
• 1 x PCIe 3.1 x 16 to 4 x SAS SFF-8643 card
• 1 x User Manuall
• 4 x SAS SFF-8643 cable
Note: Contents may vary depending on country and market.
