FEATURES

• PCIe 2.0 Gen 1 compliant

• x1 Link, dual simplex, 2.5Gbps in each direction

• Supports x1, x2, x4, x8, x16 (lane) PCI Express Bus connector keys.

• RS485 signals: DATA+ (B), DATA- (A), GND

• RS422 signal: T/R+, T/R-, RXD+, RXD-, GND

• 600W surge protection, 15 KV ESD protection for all serial ports

• Working mode: asynchronous working、point-to-point or point-to-multipoint 2 wires (half duplex) 4 wires (full duplex)

• Transmission distance: RS-485/422 port:1.2km (300bps-921600bps)

• Sleep mode with wake-up Indicator

• Transmission media: twisted-pair cable or shielded cable

• Direction control: Adopt the technology which automatically controls the data-flow direction、automatically distinguish and control the data-transmission direction;

• UART interface support for 7 or 8 data bits,1 or 2 stop bits and even/odd/mark/space/none

• Flow control none,hardware and xon/xoff

• Load capability; Support point-to-multipoint transmission. Each converter can connect 32 RS-422 or RS-485 interface equipment

• Extended operating temperature range; -40 to 85⁰C

APPLICATIONS

• Next generation Point-of-Sale Systems

• Remote Access Servers

• Storage Network Management

• Factory Automation and Process Control

System Requirements

• Windows® Server 2003, 2008, 2012

• Windows® XP, Vista, 7, 8

• Linux 2.6.27, 2.6.31, 2.6.32, 3.x.x and newer

• PCI Express-enabled system with an available PCI Express slot
